Quick 10060 Hydraulic Magnetic Circuit Breaker 60A DC - FD1006000000A00
Click to enlarge
Codex
MPN FD1006000000A00
Delivery Information
Currently we only deliver to the UK (inc. Northern Ireland), Channel Islands, Norway, Australia, New Zealand, Canada and USA for online ordering - please contact us on sales@bottomlinemarine.com if you live elsewhere.
Free shipping on UK orders over £75 (£5.95 for UK orders under £75)
Excludes certain heavy items
All prices include UK VAT - No customs or duty fees for UK orders
Description
Quick 10060 Hydraulic Magnetic Circuit Breaker 60A DC - FD1006000000A00
Part No: FD1006000000A00
The Quick 60 amp hydraulic magnetic circuit breaker offers protection when using direct currents. The slow burn circuit breaker will trip in over-current situations, breaking the circuit and protecting your equipment. They can be manually reset and are suitable for up to 80V DC. The Quick 10060 circuit breaker trips in the presence of shorts or prolonged overloads.
Brand - Quick
Voltage - Max. 80V DC
Amps - Trip Current: 60A
Approvals - CE
Height - 87mm (3-7/16")
Width - 50mm (1-31/32")
Depth - Overall: 95mm (3-3/4"), Above Surface: 28mm (1-3/32"), Behind Panel: 67mm (2-5/8")
Operating Temperature - -40°C to +85°C
Specification List
| Type | Circuit Breaker |
|---|
