Mercury - Cool Fuel Assembly Fitting Kit - Quicksilver - 22-808002A1

Genuine Mercury / Quicksilver Cool Fuel Assembly Fitting Kit. Part number 22-808002A1.

Genuine fitting kit for the Cool Fuel assembly and fuel pump and fuel cooler system on MerCruiser sterndrive engines.

Includes the fittings required to correctly assemble or service the cool fuel and fuel cooler components, ensuring secure, leak-free connections in the fuel system.

A direct OEM replacement designed to maintain the integrity of the original fuel system installation.

Fits:

• 4.3L EFI (GEN+) TBI GM 262 V-6 (S/N 0L012009–0M322780)
• 4.3L MPI ALPHA/BRAVO (S/N 0M300000–1A063239; 1A063240 & Up)
• 4.3L MPI ALPHA/BRAVO EC (S/N 1A637496 & Up)
• 5.0L EFI GM 305 V-8 (S/N 0L012052–0M299999)
• 5.0L MPI ALPHA/BRAVO (S/N 0M300000–1A623184; 1A623185 & Up)
• 5.0L MPI ALPHA/BRAVO EC (S/N 1A300000–1A623184; 1A623185 & Up)
• 5.7L EFI GM 350 V-8 (S/N 0L010035–0M299999)
• 5.7L EFI (2 BBL.-TBI) GM 350 V-8 (S/N 0K001506–0K999999)
• 5.7L EFI (GEN+) REPOWER PLUS GM 350 V-8 (S/N ALL & Up)
• 5.7L EFI MIE GM 350 V-8 (S/N 0K040300–0K261160)
• 5.7L MPI SKI (S/N 1A090000 & Up)
• 5.7LX BRAVO EFI (GEN+) GM 350 V-8 (S/N 0K001509 & Up)
• 5.7LX EFI (4 BBL.-TBI) GM 350 V-8 (S/N 0K001506–0K999999)
• 6.2L BLACK SCORPION SKI (GEN+) V-8 (S/N 0L670015–0M391599)
• 7.4L BRAVO (MPI)(GEN. VI) GM 454 V-8 (S/N 0L010003–0M024330)
• 7.4L MPI MIE (L29) GEN. VI GM 454 V-8 (S/N 0L002006–0L674613)
• 7.4L TBI MIE (LH) GEN. VI GM 454 V-8 (S/N 0F874815–0K999999)
• 7.4LX BRAVO (MPI)(GEN. VI) GM 454 V-8 (S/N 0F802000–0K999999)
• 7.4LX BRAVO (TBI)(GEN. VI) GM 454 V-8 (S/N 0F820000–0K999999)
• 8.1L INBOARD (Base) (S/N 0M026000–0W089999)
• 8.1L INBOARD (H.O.) (S/N 0M026000–0W089999)
• 8.2L MIE MPI (GEN. VI) GM 502 V-8 (S/N 0L002450–0L674200)
• 262 MAG (TBI)(GEN+) (S/N 0F803800–0K999999)
• 350 BLACK SCORPION SKI (GEN+) V-8 (S/N 0K040001–0M391599)
• 350 HORIZON BOBTAIL (S/N 1G700000–1G799999)
• 350 MAG MPI ALPHA/BRAVO (S/N 0L010019–1A623184; 1A623185 & Up)
• 350 MAG MPI ALPHA/BRAVO EC (S/N 1A300000–1A623184; 1A623185 & Up)
• 350 MAG MPI HORIZON ALPHA/BRAVO (S/N 0M300000–1A299999)
• 350 MAG MPI HORIZON ALPHA/BRAVO EC (S/N 1A300000–1A623184; 1A623185 & Up)
• 350 MAG MPI HORIZON MIE (S/N 0L302200–0M299999; 0M310000–0M398371)
• 350 MAG MPI MIE (S/N 0L302200–0M299999; 0M310000–0M398371)
• 350 MAG MPI SKI (S/N 0M300000–1A089999)
• 350 MAG MPI SKI (GEN+) GM 350 V-8 1998 AND UP (S/N 0L002600–0M310009)
• 350 MAG. ALPHA EFI GM 350 V-8 (S/N 0K001509 & Up)
• 350 MAG. BRAVO MPI GM 350 V-8 (S/N 0K001501 & Up)
• 350 MAG. EFI SKI (GEN+) GM 350 V-8 (S/N 0F820707–0K999999)
• 350 MAG. MPI MIE (GEN+) GM 350 V-8 (S/N 0L002008–0L302199)
• 350 MPI ALPHA (S/N 1G400000–1G499999)
• 350 MPI Alpha/Bravo (S/N 1G700000–1G799999)
• 350 MPI BRAVO (S/N 1G400000–1G499999)
• …and 27 more Mercury / Mariner / MerCruiser models — contact us to confirm your engine

Specifications:

• Weight: 0.021 kg
• Boxed dimensions: 2.222×2.222×2.222 cm
